SPECTREX   40/40L-111AC

SKU# (901)
SPECTREX 40/40L_-111AC

DETECTORS / FLAME DETECTORS
UV-IR

  • DESCRIPTION
  • FEATURES
  • SPECIFICATIONS
  • LITERATURE
SPECTREX SharpEye 40/40L Flame Detector with UV (ultraviolet) and IR(infrared) (2.5-3.0 um) sensor for hydrocarbon-based fuel and gas fires, hydroxyl and hydrogen fires, metal and inorganic fires. 3 Relays (Alarm, Fault and Auxiliary), 0-20mA stepped, compatible with RS-485 Modbus. Built-in-test (BIT) optional. Ex approved for Zone 1, ATEX, IECEx, FM and CSA Class I Div 1. 5 year warranty and is SIL2 (TUV) approved to IEC 61508 *** Phased Out replaced by 40/40C-LB ***

RELAYS   FM   ATEX   IECEX   CSA   UL   DIV 1   ZONE 1   SIL2   MODBUS

Inquiry

The UV/IR flame detector senses radiant energy in the short wave section of both the ultraviolet and infrared portions of the electromagnetic spectrum. The signals from both sensors are analyzed for frequency, intensity and duration. Simultaneous detection of radiant energy in both the UV and IR sensors triggers an alarm signal.

The UV sensor incorporates a special logic circuit that helps prevent false alarms caused by solar radiation.

Features
  • UV/IR Dual-Sensor
  • High-Speed Response - 150 msec Response to Saturated
    Signal
  • Solar blind
  • Automatic and Manual Built-In-Test (BIT) - to assure continued reliable operation
  • Heated window - for operation in harsh weather conditions (snow, ice, condensation)
  • Multiple output options for maximum flexibility and compatibility
    • Relays (3) for Alarm, Fault and Auxiliary
    • 0-20mA (stepped)
    • HART Protocol for maintenance and asset management
    • RS-485, Modbus Compatible
  • High Reliability - MTBF - minimum 150,000 hours
  • Approved to Safety Integrity Level 2 (SIL2 – TUV)
  • 5-Year Warranty
  • User Programmable via HART or RS-485
  • Ex approved for Zone 1 hazardous area location
    • ATEX
    • IECEx
    • FM
    • CSA
  • 3rd party Performance Tested
    • EN54-10 (LPCB)
    • FM3260 (FM)
Applications
Offshore Oil & Gas installations Printing Industry
Onshore Oil & Gas installations and pipelines Warehouses
Chemical plants Automotive Industry
Petrochemicals plants Explosives & Munitions
Storage Tank farms Waste Disposal facilities
Aircraft hangars Aerospace Industry
Pharmaceutical Industry Paint, Polymer and Glue
processes

GENERAL SPECIFICATIONS
Spectral Response 40/40L–LB: UV: 0.185 - 0.260 μm; IR: 2.5-3.0 μm
40/40L4–L4B: UV: 0.185 - 0.260 μm; IR: 4.4-4.6 μm
Detection Range
(at highest Sensitivity Setting for 1ft2 (0.1m2) pan fire)
Fuel ft / m
n-Heptane 50 / 15
Gasoline 50 / 15
Diesel Fuel 37 / 11
JP5 37 / 11
Kerosene 37 / 11
Ethanol 95% 25 / 7.5
Methanol 25 / 7.5
IPA (Isopropyl Alcohol 25 / 7.5
Hydrogen** 16 / 5
Methane* 16 / 5
LPG * 16 / 5
Polypropylene Pellets 13 / 4
Office Paper 16 / 5
* 20" (0.5m) high, 8" (0.2m) width plume fire
** 40/40L/LB only
Response Time Typically 5 seconds. High speed 150 msec response to saturated signal
Adjustable Time Delay Up to 30 seconds
Sensitivity Ranges 1 ft2 (0.1m2) n-heptane pan fire from 50 ft (15m)
Field of View Horizontal 100º; Vertical 95º
Built-in-Test (BIT) Automatic (and Manual)
Temperature Range Operating: -67ºF to +167ºF (-55ºC to +75ºC)
Option: -67ºF to +185ºF (-55ºC to +85ºC)
Storage: -67ºF to +185ºF (-55ºC to +85ºC)
Humidity Up to 95% non-condensing (withstands up to 100% RH for short periods)
Heated Optics To eliminate condensation and icing on the window
ELECTRICAL SPECIFICATIONS
Operating Voltage 24 VDC nominal (18-32 VDC)
Power Consumption Standby: Max. 100mA (150mA with heated window)
Alarm: Max. 150mA (200mA with heated window)
Cable Entries 2 x 3/4" - 14NPT conduits or 2 x M25 x 1.5 mm ISO
Wiring 12 - 22AWG (2.5mm 2 - 0.3mm 2)
Electrical Input Protection According to MIL-STD-1275B
Electromagnetic Compatibility EMI/RFI protected to EN50130-4
Electrical Interface The detector includes twelve (12) terminals with five (5) wiring options (factory set)
OUTPUTS
Relays Alarm, Fault and Auxiliary
SPST volt-free contacts rated 5A at 30 VDC or 250 VAC.
0-20mA (stepped) Sink (source option) configuration
Fault: 0 +1mA
BIT Fault: 2mA ± 10%
Normal: 4mA ± 10%
IR: 8mA ± 5%
UV: 12mA ± 5%
Warning: 16mA ± 5%
Alarm: 20mA ± 5%
Resistance Loop: 100-600 Ω
HART Protocol HART communication on the 0-20mA analog current (FSK) - used for maintenance, configuration changes and asset management
RS-485 RS-485 Modbus compatible communication link that can be used in computer controlled
installations
MECHANICAL SPECIFICATIONS
Materials
Enclosure options		 - Stainless Steel 316L with electro polish finish
- Heavy duty copper free aluminum (less than 1%), red epoxy enamel finish
Mounting Stainless Steel 316L with electro polish finish
Dimensions Detector 3.5" x 4.5" x 6.1" (90 x 114 x 156 mm)
Weight Detector (St.St.) 5.5 lb (2.5 kg)
Detector, aluminum 2.5 lb (1.2 kg)
Tilt mount 2.2 lb (1.0 kg)
Environmental Standards Meets MIL-STD-810C for Humidity, Salt & Fog, Vibration, Mechanical Shock, High Temp, Low Temp
Water and Dust IP66 and IP67 per EN60529, NEMA 250 6P
APPROVALS
Hazardous Area
ATEX and IECEx Ex II 2 GD,
  Ex de IIB+H2 T5 o (-5+55 ºCºC 7 x de IIB+H2 T4 (-55ºC to + 85ºC)
  Ex tD A21 IP66/X7 T 95ºC Ex tD A21 IP66/X7 T 105ºC
FM / CSA Class I Div. 1, Groups B, C & D
  Class II/III Div. 1, Groups E, F & G
Performance EN54-10 (LPCB)
FM-3260 (FM)
Reliability IEC61508 - SIL2 (TUV)
ACCESSORIES
Fire Simulator20/20-310
Weather Protector777163
Laser Pointer
(Detector area coverage)		777166
Tilt Mount40/40-003
Air Shield777161
Export Info
Made inUnited States
Harmonized Tariff Code (HTC)90318099
