E2S   D2xH1VN01AB1E1RN

SKU# (7279)



E2S D2xH1VN01AB1E1RN

DETECTORS / THERMAL
INTELLIGENT

  • DESCRIPTION
  • FEATURES
  • SPECIFICATIONS
  • LITERATURE
E2S D2xH1 Heat Detector for harshest of environments. Stainless steel casing and hermetically sealed contacts. Class I Zone 2 and Zone 22, Class I/Class II Div 2. IECEx, ATEX, UL, ULC and cUL approvals. IP66/IP67.

UL   ATEX   IECEX   DIV 2   ZONE 2

D2xH1VN01AB1E1RN
Please Email us your request for quote

Element orientation
Element guard
Temperature code
Cable entries
All types also contain 2 × 3/4” NPT side & 1 × 3/4” NPT pendant entries
Stopping plug/adaptor material
Equipment tag
Product version
Versions E, I & R: IECEx, ATEX, UL, cUL, ULC
Enclosure colour
LED indicator

  [  2 Weeks  ]
251 Variants of base SKU / 30 Shown below

The E2S D2xH1 globally certified heat detector provides a comprehensive solution suitable for the harshest of environments. Featuring the D-A-F rate compensated heat detector elements with stainless steel casing and hermetically sealed contacts. The D2xH1 is approved for Class I Zone 2 AEx db ec, Ex db ec, Zone 22 AEx tc/Ex tc, Class I/II Div 2 applications plus versions certified as intrinsically safe. Global approvals include IECEx, ATEX, UL, ULC and cUL.

The ro bust IP66/67, Type 4/4X co rro sio n pro o f junctio n bo x enclo sure is manufactured fro m marine grade, co pper free LM6 aluminium. The E2S D2xH1 heat detecto r o ffers a ro bust and reliable so urce fo r alarm initiatio n in the mo st hazardo us and demanding o f applicatio ns.

Features
  • Robust corrosion proof LM6 marine grade aluminium enclosure
  • Ingress protection IP66/67 Type: 4/4X
  • Compact enclosure
  • Multiple cable entries
  • Stopping plugs supplied
  • UL521 and CAN/ULC-S530 approved
  • EN54-5 compliant
  • D-A-F rate compensated heat detector elements
  • Versatile: various temperature settings available
  • Durable: long lasting stainless steel element shell
  • Reliable: hermetically sealed internal contact area
  • Economical: wide installation spacing reduces installation costs
  • Factory set temperature
  • Globally approved to IECEx, ATEX, UL, cUL and ULC standards
  • Version E: Zone 2, Zone 22, Class I/II Div 2
  • Version I & R: Zone 0, Zone 21, Class I/II Div 1
Approvals
  • UL/cUL – File ref: E245313
  • IECEx ULD 14.0004X
  • ATEX DEMKO 14ATEX4786493904X
  • UKCA UL21UKEX2131X
  • SIL2 compliant to IEC61508 (2010)

Specification
Enclosure:Marine grade LM6 aluminium
Enclosure colour:Red or Grey
Enclosure finish:Chromate & powder coated finish
Ingress protection:IP66/67 EN50029, Type 4/4X UL50E
Cable entries:2 × 3/4"NPT with 2 x M20x1.5mm or 2 × 1/2"NPT Stopping plug(s) included
Cable spec:Solid core: 0.5-2.5mm2 AWG20-12
Stranded core: 0.5-2.5mm2 AWG24-14
Terminals:DIN Rail AKZ 2.5 × 6
Max Input32Vdc: 1A, 24Vdc: 2A, 32Vac 50/60Hz: 5A – version E
Max Power1.25W – version E
Safety parameters:Ui=30V, Ii=500mA, Pi=1100mW, Ci=0, Li=0 – version I & R
Stopping plugs:Brass, Nickel Plated or Stainless Steel
Grounding stud:M5
Installation temp:-40° to +50°C (-40°F to +122°F)
Storage temp:-40° to +50°C (-40°F to +122°F)
Weight:1.5kg/3.31Ibs
Export Info
Made inUnited Kingdom
Harmonized Tariff Code (HTC)8531800010
