Gas Leak and Flame Detectors, Analyzers, Alarm Devices and Calibration Gas
SKU# (4750)

ESP SAFETY  100-0008-A1/100-0015-Cl2

$1,440.00     Availability: 3 Weeks
 Info/Quote Request
 Shipping Rates
 Volume discount



ESP SAFETY 100-0008-A1/100-0015-Cl2 (1)
  • DESCRIPTION
  • FEATURES
  • SPECIFICATIONS
  • LITERATURE

ESP Safety Vector 2-channel gas detector controller with smart Plug-In Sensor to Detect Chlorine (Cl2) 0-10ppm. Operates as a stand-alone display for a variety of ESP sensors which can be remotely located up to 500 feet away over 4-wire RS-485. Sensor head can also be attached. Includes analog 4-20 current loop with HART, Digital RS-485 Modbus RTU and 4 relays. 96-Character OLED Screen. Explosion-proof housing. IP67. SIL 2, FM/CSA Class I Division 1 certification.

Part# with Options:        100-0008-A1/100-0015-Cl2
Price with Options:        1,440.00

Options:

Optional Sensor
(1) Sensor for ESP Safety Vector

  Availability 3 Weeks  ]


ESP Safety’s Vector is a state-of the-art field control unit that performs as an integrated control terminal and display for ESP Safety’s gas detector product line.

The Vector can operate as a stand-alone display for a variety of ESP Safety’s detectors which can be remotely located up to 500 feet away. A sensor head can also be attached directly to the display housing to produce a unified detector/display unit.

Key Features
  • A vivid, 2.7” (diagonal) 128x64 pixel resolution, OLED screen simultaneously displays a wide range of data including gas concentrations, alarm levels, faults and operational modes.
  • Analog 4-20 current loop w/ HART , Digital RS-485 Modbus RTU and 4 relays are standard data communication channels of the VECTOR FCU
  • Event log is stored in on-board memory and is accessible via RS-485 Modbus RTU
  • Operating Temp Range of -58°F to +167°F (-50°C to +75°C)
  • Configurable to control & monitor up to 2 detectors
  • SIL certification by independent 3rd party agency
  • 316 Stainless Steel construction, explosion-proof housing, Class 1, Division 1
  • Non-Instrusive, on-site detector calibration via a HART Field Communicator or Magnectic Wand
Applications
  • Offshore platforms
  • Land rigs
  • Shipping tankers, freighters, and other vessels
  • LNG/LPG processing & storage facilities
  • Oil & gas refineries
  • Petrochemical plants
  • Gas & electric utilities
Additional Features
  • Non-intrusive operator interface is easily achieved by contacting a magnetic wand with the glass housing cover and accessing the intuitive, menu-driven programming screen
  • Tri-color status LED indicates operational mode, fault & gas presence
  • Two - Analog 4-20mA Relay Outputs
  • Four - Direct Relay Outputs are standard

Specifications
Electrical Characteristics
Voltage+24VDC Nominal (+18 to 32VDC)
Power4.3 W, standby 5.3 W, during alarm
12.0 W with heater on (temp ≤ 30°C)
OutputsAnalog signal: 2x +4-20mA
Digital RS-485 Modbus RTU
HART communication port
Three User Programmed Alarm Relays
One Fault Condition Programmed Relay
Technical Specifications
Humidity0 to 100% relative humidity, non condensing
Operating Temperature-58°F to +167°F (-50°C to +75°C)
-76°F to +167°F (-50°C to +75°C), with heater enabled
Storage temperature-76°F to +185°F (-60°C to +85°C)
Ingress ProtectionIP67
SIL RatingSIL 2, FM/CSA Class I Division 1 certification
Mechanical Characteristics
Material316 Stainless Steel
Conduit Connection5 Conduit Entrances , 3/4” NPT
Dimensions7.50” x 5.60” x 4.28”
Weight12.8 lbs (5.8 kg)
Warranty5 years



B2B Checkout Options: Designated Carrier and Tax-Exempt purchase
Payment Options: Credit Card, Credit Card Over the Phone, PAYPAL, Wire Transfer and Check

Checkout with Paypal Visa MasterCard Amex Checkout with Wire Transfer Electronic Payment

> ACCESSORIES - RELATED - CONSUMABLES :    1 Items found.
100-0015-CL2
(5815)

ESP SAFETY  100-0015-CL2

ESP Safety Sensor Assy, PGU-Clorine (CL2); Plug-in sensor & stainless steel housing. Includes weather protective dust cap.



$690.00
> CHLORINE :    22 Items found.
M001-0004-000
(5995)

MPOWER  M001-0004-000

mPower UNI MP100 Portable Single Gas Detector for detection of Chlorine (Cl2) 0-50ppm. Includes large LCD display, 6 Bright Red Flashing LED, Vibrating and 90dB Audible Alarm Port. IP67, Event Logger, ATEX and UL approval for Class I Div 1.



$268.20
PC3-6924
(6810)

PROSENSE  PC3-6924

Prosense PC3-6924 Gas Detector with Electrochemical sensor for Chlorine (Cl2) with range 0-10 ppm. Epoxy painted aluminum housing and Nickel Plated Brass sensor head. 4-20mA Analog and Modbus RS485 RTU outputs. Optional Relay Outputs. IP65, Zone 2.

Configure

$414.00
BWS_-C-Y
(6384)

BW  BWS-C-Y

BW Solo Serviceable Single-gas Detector for Chlorine (Cl2) 0-50 ppm. Small and lightweight. One button operation, 3.6V 1.65Ah Lithium Battery. Visual, vibrating and audible alarms. Optional wireless version. IP66/68. ATEX, IECEx and CSA approvals for Class I Div 1.

G02-B610-100
(3021)

RAE  G02-B610-100

ToxiRAE Pro PGM-1860 Personal Portable Monitor For Chlorine (Cl2) 0-50 ppm with replaceable sensor, filter and Li-ion battety. Automatic bumb testing and calibration with AutoRAE 2 (optional). Includes Datalogging, Graphical LCD display, 2 buttons for operation and programming. CSA, ATEX, IECEx and China Ex Approved. IP-65. Wireless-capable option.

P-6934
(6785)

PROSENSE  P-6934

Prosense P-6934 Gas Detector with Electrochemical sensor for Chlorine (Cl2) with range 0-10ppm. Ex-proof housing and SS316 stainless steel sensor head. 4-20mA Analog and Modbus RS485 RTU outputs, optional Relay card. ATEX/IECEx approval (Zone 1 or Zone 2). IP65, Optional IP66 Adaptor.

Configure

$693.00
10154080
(4401)

MSA  10154080

MSA ALTAIR 2X Portable Single Gas Detector with XCell Sensor Technology for Chlorine (Cl2) Range 0-10 ppm. Low Alarm 0.5ppm, High Alarm 1ppm. Polycarbonate Housing. 25 feet drop test. 95dB audible alarm. Monochrome LCD Display. IP67. cCSAus, ATEX and IEC Approved.



$715.92
SPSTAXL1
(1482)

HONEYWELL  SPSTAXL1

Honeywell Zareba Sensepoint Gas Detector Transmitter for Chlorine (Cl2) 0-5ppm complete with pre-wired universal junction box (1 threaded M20, 1 clearance 3/4"NPT, 1 clearance 1/2" NPT, 3 approved stopping plugs, earth continuity plate) and factory set toxic gas sensor. 2 wire 4-20mA loop output. ATEX Approved. (Optional ranges: 0-5 ppm, 0-15 ppm)

Configure

$752.30
364-455-01-365-782-11
(6151)

DELPHIAN  364-455-01-365-782-11

Delphian GazTell Fixed Point Electrochemical Gas Detector for Chlorine (Cl2) 0-10 ppm. 4-20mA Output. Optional Modbus RTU Output and Alarm Relays. SIL2 Approval. Suitable for Class I Div 1 & 2 Groups C, D.

Configure

$758.40
GG-CL2-B-5
(2962)

CALIBRATION TECHNOLOGIES  GG-CL2-B-5

CTI GasGuard Cl2 Chlorine Electrochemical Sensor (0-5 ppm) for gas leak detection in process areas, tank storage, sanitizing systems and others. No false alarms. 4-20 mA output, 24VDC power supply and NEMA 4X polycarbonate enclosure.

Configure

$900.90
1100ALD-109014/01P
(6910)

RC SYSTEMS  1100ALD-109014/01P

RC Systems SenSmart 1100 gas detector for Chlorine (Cl) 0-1ppm to 0-50ppm with 'ST-48' smart transmitter. Electrochemical sensor. 2-Wire 4-20mA output. 10-30 VDC. Aluminum or Stainless Steel enclosure. Suitable for Class 1 Div 1 (Explosion Proof).

Configure

$914.78
PQN-6934-1/2
(6958)

PROSENSE  PQN-6934-1/2

Prosense PQN-6934 Gas Detector with Electrochemical sensor for Chlorine (Cl2) with range 0-10ppm. Ex-proof housing and SS316 stainless steel sensor head. 4-20mA Analog and Modbus RS485 RTU outputs, optional Relay card. ATEX/IECEx (Zone 1, Zone 2 or M2) approvals, optional SIL2. IP65, Optional IP66 Adaptor and remote display.

Configure

$945.00
PQD-6934-1/2
(6746)

PROSENSE  PQD-6934-1/2

Prosense PQD-6934 Gas Detector with Electrochemical sensor for Chlorine (Cl2) with range 0-10ppm. Ex-proof housing and SS316 stainless steel sensor head. 4-20mA Analog and Modbus RS485 RTU outputs, optional Relay card. OLED Display. ATEX/IECEx (Zone 1, Zone 2 or M2) approvals, optional SIL2. IP65, Optional IP66 Adaptor.

Configure

$1,071.00
GG-CL2-5-EXP
(5977)

CALIBRATION TECHNOLOGIES  GG-CL2-5-EXP

CTI GG-CL2-EXP Explosion Proof Electrochemical Gas Sensor for Chlorine (Cl2) 0-5 ppm. 4-20 mA output, 24VDC power supply. Explosion Proof Copper-free aluminum enclosure for Class l, Div 1 & 2, Groups B, C & D. CSA, UL, FM, ATEX and IECEx approved.

Configure

$1,110.20
2106B1410
(1456)

HONEYWELL  2106B1410

Honeywell Sieger Sensepoint Gas Detector Transmitter for Chlorine (Cl2) (0-5 ppm to 0-15 ppm) with Surecell Toxic Sensor. 2 wire 4-20mA loop output. ATEX/IECEx CSA Class I Division 2 Certified.

Configure

$1,135.98
S3KUL2-XNXXSL1SS
(687)

HONEYWELL  S3KUL2-XNXXSL1SS

Honeywell Series 3000 MkII Gas Detector Transmitter, with aluminum housing (optional stainless steel) for monitoring CHLORINE (CI2) with electrochemical sensor, 2-wire 4-20mA loop, LCD Display, 0-5.0ppm, user adjustable (5.0 to 20.0ppm, 5.0ppm increments) Available Approvals UL Class I, Div 1 & 2, ATEX Zone 0 and IECEx.

Configure

$1,471.45
2100AL-0-9014/01P/L0
(118)

RC SYSTEMS  2100AL-0-9014/01P/L0

RC Systems SenSmart 2100 2 wire 4-20mA Loop Powered gas detector for Chlorine (Cl) 0-1ppm to 0-50ppm with 'ST-48' smart transmitter. Includes Graphic LCD Display, LED indicator and 4-20mA output. 10-30 VDC. Poly or aluminum enclosure. Suitable for Class 1 Div 1 & 2 (Explosion Proof).

SPXCDULNL2
(1898)

HONEYWELL  SPXCDULNL2

Honeywell Sensepoint XCD RTD Gas Detector for Chlorine (Cl2) with Electrochemical Sensor. Aluminium alloy LM25 or 316 stainless steel housing, PPS sensor head, tri-color backlit LCD Display. IP67. 3-wire 24 VDC power. Includes 3 programmable alarm relays and 4-20mA output (sink or source selectable), Modbus RTU option available. User-Selectable full scale range 0 to 5 ppm. UL/cCSAus Approved for Class I Div 2. Remote Sensor Option.

Configure

$1,572.89
961-740026-010G
(6353)

DETCON  961-740026-010G

Detcon DM-100-CL2 Electrochemical Chlorine (Cl2) 0-10ppm Sensor Assembly with optional loop powered display. 4-20 mA. Features intelligent electronices, non-intrusive operator interface and comprehensive fault diagnostics. Optional 316 Stainless Steel Housing. 3/4" NPT thread. XP-instrinsically safe. Class I, Div. 1, Groups A, B, C, & D.

Configure

$1,628.24
31001AL___-0-9014/01P/L0
(6889)

RC SYSTEMS  31001AL-0-9014/01P/L0

RC Systems SenSmart 3100 3 wire gas detector for Chlorine (Cl) 0-1ppm to 0-50ppm with 'ST-48' smart transmitter. Includes Graphic LCD Display, LED indicator and 4-20mA output. 10-30 VDC. Aluminum or Stainless Steel enclosure. Suitable for Class 1 Div 1 (Explosion Proof).

Configure

$1,722.50
EX-CL2-5P-O
(6017)

MACURCO  EX-CL2-5P-O
