E2S   GPH3SEDC024G

SKU# (3647)



E2S GPH3SEDC024G

ALARM SIGNAL DEVICES / WEATHERPROOF
HORNS

  • DESCRIPTION
  • FEATURES
  • SPECIFICATIONS
  • LITERATURE
E2S GPH3 Surface Mount Alarm Horn-Buzzer 110dB(A). Low current consumption and high SPL. Robust and fire retardant housing. Stainless Steel fixings. 10-30VDC/AC or 40-260VDC/AC Versions. IP66. UL and cULs Approved.

UL

GPH3SEDC024G
Please Email us your request for quote

Voltage
Metric Adaptor

  [  2 Weeks  ]
2 Variants of base SKU

The GPH series are low profile, high output, 110dB(A) alarm horns designed as a maintenance free, reliable alternative to solenoid type devices. Featuring a realistic simulated buzzer sound the GPH, with its low current consumption and high SPL in a robust, fire retardant housing, is suitable for all general signalling applications.

The GPH3 is a surface mount version with back box, the GPH4 is a flush mount variant for use in panel mount applications or for use with standard 4" back boxes

Features:
  • Automatic synchronisation on multi-sounder system.
  • Continuously rated.
  • Stainless steel fixings.
  • Duplicate cable terminations (in & out for daisy-chain installations).
Approvals:

  • UL & cULs approved: G eneral signalling use.

Specification
Nominal output: 110dB(A) @ 1m +/- 3dB [101dB(A) @ 10ft/3m]
No. of tones: 3
Stage switching: DC voltage via negative
AC voltage via live supply
Volume control: On board potentiometer
Voltages DC: 10-30V dc/ac
Voltages AC: 40-260V dc/ac
Ingress protection: GPH3: IP66 (UL Type 4/4X/13)
GPH4: IP54 (UL Type 13/3R)
Housing material: High impact UL94 V0 (f1) PC
Colour: Grey (RAL7038)
Cable entries: 2 x M20 clearance
Terminals: 22 - 12 AWG (0.5-3mm2)
Operating temp: -25 to +55°C [-13° to +131°F]
Storage temp: -40 to +70°C [-40° to +158°F]
Relative humidity: 90% at 20°C [68°F]
Weight: 0.40kg/0.88Ibs
*SPL data +/-3dB(A). Measured at optimum voltage.
Export Info
Made inUnited Kingdom
Harmonized Tariff Code (HTC)85318030
