Rc Systems 55001al-0-9027/100p/l0 | Voc Pid | Gas Detectors (explosion-proof) | Gasdetectorsusa
Gas Leak and Flame Detectors, Analyzers, Alarm Devices and Calibration Gas

RC SYSTEMS   55001AL-0-9027/100P/L0

SKU# (7120)



RC SYSTEMS 55001AL-0-9027/100P/L0

DETECTORS / GAS DETECTORS (EXPLOSION-PROOF)
VOC PID

$3,398.70  [3 Weeks]
  • DESCRIPTION
  • FEATURES
  • SPECIFICATIONS
  • LITERATURE
RC Systems SenSmart 5500 3-wire gas detector for Volatile Organic Compounds VOC 10.0eV or 10.6eV with GEN2 smart sensor, Color backlit LCD Display and 4-20 mA output, 10-30 VDC. Aluminum or Stainless Steel enclosure. CSA Class I Div 1 (Explosion-Proof). Optional 2 RS-485 Modbus ports, 2 Programmable Alarm and Fault Relays, HART.

DISPLAY   4-20 mA   RELAYS   CSA   UL   DIV 1   HART   MODBUS

55001AL-0-9027/100P/L0
3,398.70

Enclosure Type
Model
Output
Sensor Type
Splash Guard / Remote Sensor

  [  3 Weeks  ]
251 Variants of base SKU / 30 Shown below

The state-of-the-art SenSmart 5000 gas detector is R.C. Systems’ newest release to the gas detection industry. No competitive product offers as many features or better performance to cost ratio. With a bright, vivid backlit color display, Modbus and programmable relays, it will satisfy the most demanding application’s requirements. The high performance, universal gas detector supports all temperature compensated smart sensor types including Electrochemical, Catalytic Bead, Infrared and Photoionization sensors. It even has Arctic options available for extreme low temperature installations.

FEATURES HIGHLIGHT
  • CSA Certification for Class 1, Div 1 and Class 1 Div 2 locations
  • Color backlit LCD Display
  • Display Color Changes with Alarm Status
  • Generation 2 Smart Sensor Compatible for increased signal stability
  • Sensor Life Indication
  • Remote Sensor Mount up to 4000’
  • Non-intrusive One-Man Calibration
  • Temperature Compensation
  • Two RS-485 Ports for Modbus
  • 2 Programmable Relays and Fault Relay Available
  • Heated elements available for low temperature
  • Remote SmartCal feature allows user to initiate calibrations from connected RCS controller via Modbus connection

SPECIFICATIONS
Power Supply10-30VDC at < 6.5 watts with relay board (all relays energized)
Display128x64 pixel color backlit LCD display
Sensor InputElectrochemical, Catalytic Bead, Infrared, Photoionization Detector sensor, Modbus 4-20mA
Standard Output3-wire 4-20mA current source. Max loop Resistance 600 ohms @ 24VDC
Optional OutputsTwo programmable relays plus dedicated FAULT relay
Dual master / slave MODBUS RS-485 serial interfaces
EnvironmentalOperating range -40°C to +60°C Sensors include sensor heater for low temperature operation Relative humidity to 95% for IR; to 85% noncondensing when using electrochemical sensors
HousingAluminum with epoxy paint standard; Optional #316 stainless steel, Optional Ul94 Poly Black Plastic Enclosure
Dimensions(Aluminum) Width 5.4” (137 mm), Height 8” (203 mm), Depth 5” (127 mm) Shipping weight 6.5 pounds (3 kg)
(Poly) Width 5” (127 mm), Height 7” (178 mm), Depth 4” (101 mm) Shipping weight 3 pounds (2 kg)
ApprovalsCSA Certification for: Class I, Div1, Group A, B, C, D , Class I, Zone 1, Group IIC, T4
Class I, Div 2 Groups A, B, C, D, Class I, Zone 2, Group IIC, T4,
Warranty1 year* see standard warranty clause on our website
Export Info
Made inUnited States
Harmonized Tariff Code (HTC)9027102000

 Info/Quote Request
 Reseller & Volume Discounts
 Shipping Rates

B2B Checkout Options: Designated Carrier and Tax-Exempt purchase
Payment Options: Credit Card, Credit Card Over the Phone, PAYPAL, Wire Transfer/Electronic Payment and Check

Checkout with Paypal Visa MasterCard Amex Checkout with Wire Transfer Electronic Payment
