PROSENSE   PEC-632

SKU# (7697)
PROSENSE PEC-632

GAS DETECTION CONTROLLERS / MULTI-POINT CONTROLLERS
32-CHANNEL

$505.44  [7 Days]
  • DESCRIPTION
  • FEATURES
  • SPECIFICATIONS
  • LITERATURE
Prosense PCE-632 Series Gas Control Panel for 32 x RS485 MODBUS RTU Detectors. Simultaneously monitors measurement levels, alarm and fault status. 24 VDC. Includes 5 relays, sound and visual alarm, LCD display, LED indicators and buzzer. IP20.

DISPLAY   RELAYS   MODBUS

PEC-632
$505.44

  [  7 Days  ]

Prosense PEC-600 Series Gas Control Panel is able to provide automatic gas concentration reading and protection against gas hazards. Panel permanently transmits the gas concentration measurement from detectors and instantly handles the measurement of detectors. The control panel is able to generate sound and visual alarm, when measurements reach the programmed limit value. LRP Series Gas Control Panel built as a electric panel mounted system.

Prosense PEC-600 Series Control Panel has three levels of alarm which are adjustable according to the measuring range and one fault alarm for the detection loop. Individual relays per function ensure remote controlled output. There are 5 relays on the panel. Three of them used as alarm relays and configured as ALARM-1, ALARM-2 and ALARM-3. There is one FAULT relay to monitor overall fault status. An additional relay can be programmed for optionally adjusted to alarm status.

PEC-616 and PEC-632 models provide MODBUS communication to detectors for monitoring through serial connectivity.

Specifications
Inputs PEC-632: 32 x RS485 MODBUS RTU Detectors
Monitoring Simultaneously monitoring measurement levels, alarm and fault status
Relay Outputs Programmable FAULT, ALARM1, ALARM2, ALARM3, AUX (optional programmable relay)
Both NO/NC contacts available
Display LCD 16x2
LED Indicators DETECTOR FAULT, ALARM and SYSTEM FAULT LEDs for overall monitoring
Buzzer YES
Programming User friendly software enables easy programming with 4 buttons on panel door
Remote Monitoring Optional computer based remote monitoring for PCE-604 and PCE-606
Power Supply 24 VDC
Main Power Fuse 2A
Power Consumption 27VDC/250mA - 4W max. (without connected detectors)
Ingress Protection IP20
Humidity 10-95% RH Non-Condensing
Operating Temp. -20° to +60°C
Panel Material PC (Polycarbonate), Halogen-free, Silicon-free, Durable 960' Hot Wire Experiment, Resistant to UV Rays
Dimensions/Weight 120x90x50mm / 250 Gr
Mounting Modular Structure / Inside the control or electric panel
Export Info
Made inTurkey
Harmonized Tariff Code (HTC)8531100045

 Info/Quote Request
 Reseller & Volume Discounts
 Shipping & Handling

B2B Checkout Options: Designated Carrier and Tax-Exempt purchase
Payment Options: Credit Card, Credit Card Over the Phone, PAYPAL, Wire Transfer/Electronic Payment and Check

Checkout with Paypal Visa MasterCard Amex Checkout with Wire Transfer Electronic Payment
