SPECTREX QTU-QRU-C-2111

Name: SPECTREX QTU-QRU-C-2111 OPEN PATH AMMONIA
Brand: SPECTREX
SKU: 6984
Price: 27342.56 USD
Availability: PreOrder

SKU# (6984)

Be the First to Review this Item

DETECTORS / OPEN PATH
AMMONIA

Reseller & Volume Discounts

$27,342.56 [12 Weeks]

DESCRIPTION
FEATURES
SPECIFICATIONS
LITERATURE

SPECTREX SafEye Quasar 960 open path gas detector and source with ultraviolet technology to detect toxic Ammonia (NH3) at very low concentrations. Long range and high speed response. 24 Vdc. 0-20 mA, HART and RS-485 Modbus outputs. Stainless steel housing. IP66 and IP68. NEMA 250 6P. FM, ATEX, IECEx, CSA and SIL2 approvals.

QTU-QRU-C-2111 Spell
27,342.56

Certification

Model

Entry Size

Certificates

	[ 12 Weeks ]
30 Variants of base SKU QTUQRUC2111 QTUQRUC2112 QTUQRUC2211 QTUQRUC2212 QTUQRUC2311 QTUQRUC2312 QTUQRUA2111 QTUQRUA2112 QTUQRUA2211 QTUQRUA2212 QTUQRUA2311 QTUQRUA2312 QTUQRUB2111 QTUQRUB2112 QTUQRUB2211 QTUQRUB2212 QTUQRUB2311 QTUQRUB2312 QTUQRUR2111 QTUQRUR2112 QTUQRUR2211 QTUQRUR2212 QTUQRUR2311 QTUQRUR2312 QTUQRUK2111 QTUQRUK2112 QTUQRUK2211 QTUQRUK2212 QTUQRUK2311 QTUQRUK2312

The SafEye Quasar 960 is part of he innovative SafEye Quasar open path gas detector series. The detector provides ultraviolet technology continuous monitoring for toxic ammonia (NH3) gas at very low concentrations, up to 95 percent obscuration, featuring advanced wide area coverage with long range detection up to 200 ft. (60 m) and high speed response in under 10 seconds.

The SafEye Quasar 960 is solar blind and immune to industrial environments, ensuring reliable and accurate protection to keep a SafEye on your safety.

Features and benefits

Detects toxic ammonia (NH3) at up to 200 ft. (60 m)
Accurate and reliable high-speed response in under 10 seconds
Uses ultraviolet technology
High false alarm immunity
Solar blind and immune to industrial environments
Built-in event recorder; real time record of the last 100 events
Strengthened reliability and durability with a massive three-year warranty
Easy installation and maintenance
Heated window for operation in harsh weather conditions (snow, ice, or condensation)
Detection of a cloud of gas at very low concentrations, up to 95 percent obscuration
User programmable via HART � or RS-485 Modbus � ; compatible with modern user interface for ease of use
Certified performance/Hazardous Area approved (ATEX, IECEx, CSA, and more) for location in Zone 1 areas
Approved to Safety Integrity Level 2 (SIL2 - T�V)
High reliability-MTBF-minimum 100,000 hours

Applications

Agriculture
Food and beverage
Chemical
Waste management
Water treatment
Pharmaceutical

General specifications
Detected gas	Ammonia (NH3)
Response time	< 3 seconds (T90 < 10 seconds)
Immunity to false alarms	Not influenced by solar radiation, hydrocarbon flames, and other external infrared radiation sources
Sensitivity range	0-500 ppm.m
Spectral response	200-300 nm
Displacement/misalignment tolerance	�1 degree
Drift	Long term �5 percent of full scale
Temperature range	-67 to +149 �F (-55 to +65 �C)
Humidity	Up to 95 percent non-condensing (withstands up to 100 percent relative humidity for short periods)
Heated optics	To eliminate condensation and icing on the window
Warranty	Safety system: three years
Electrical specifications
Power supply	24 Vdc nominal (18-32 Vdc)
Power consumption (peak includes heated optics)	Detector: 250 mA (300 mA peak) Source: 250 mA (300 mA peak)
Warm-up time	60 seconds for transmitter and receiver
Electrical connection (specify)	Two �-in. - 14 national pipe thread (NPT) conduits or 2 x M25 x 1.5 mm ISO
Electrical input protection	According to MIL-STD-1275B
Electromagnetic compatibility	Electromagnetic interference/radio frequency interference (EMI/RFI) protected to EN50270
Outputs - interfaces
0-20 mA current output	Sink (source option) configuration: maximum load of 500 ohm at 18-32 Vdc Gas reading: 0-20 mA Normal, zero reading: 4 mA Maintenance call: 3 mA Misalignment: 2.5 mA Obscuration/beam block: 2 mA Zero calibration mode: 1 mA Fault: 0 mA
RS-485 interface - Modbus � compatible	RS-485 Modbus compatible communication link that can be used in computer controlled installations
HART � protocol	Optional HART communications on the 0-20 mA analog current (FSK) - used for maintenance and asset management
Visual status indicator	Three color light emitting diode (LED) Green: power on Yellow: fault Red: alarm
Outputs - interfaces
Enclosure	The source and detector housings are stainless steel 316L with electro polish finish. The circuit boards are conformal coated and protected from mechanical vibrations. The tilt mount is also stainless steel 316L.
Dimensions	Detector/source: 10.5 x 5.1 x 5.1 in. (267 x 130 x 130 mm) Tilt mount: 4.7 x 4.7 x 5.5 in. (120 x 120 x 158 mm)
Weight	Detector/source: 11 lb. (5 kg) Tilt mount: 4.2 lb. (2 kg)
Water and dust tight	IP66 and IP68 per EN60529, NEMA 250 6P
Environmental standards	Meets MIL-STD-810C for humidity, salt and fog, vibration, mechanical shock, high temperature, and low temperature
Reliability	SIL2 per IEC61508 (TUV)

Export Info
Made in	United States
Harmonized Tariff Code (HTC)	9027102000
