E2S   STEXS1RDC024AS2A1R

SKU# (6458)



E2S STEXS1RDC024AS2A1R

ALARM SIGNAL DEVICES / ATEX
HORNS

  • DESCRIPTION
  • FEATURES
  • SPECIFICATIONS
  • LITERATURE
E2S STExS1R 115dB(A) Alarm Horn Sounder with omni-directional horn. IP66 corrosion proof 316L stainless steel enclosure. 64 channel alarm sounds. 3 cable entries. Remotely triggering. Suitable for All Zone 1, 2, 21 & 22. IECEx and ATEX Approved.

ATEX   IECEX   ZONE 1

STEXS1RDC024AS2A1R
Please Email us your request for quote

Voltage
Cable Entries
Stopping plug/adaptor material
Bracket
Metric Adaptor

  [  2 Weeks  ]
168 Variants of base SKU / 30 Shown below

The STExS1R is a high output, 115dB(A) alarm horn sounder with a omni- directional horn. Low current consumption and high SPL in a robust IP66 corrosion proof 316L stainless steel enclosure ensures suitability for all Zone 1, 2, 21 & 22 applications.

Featuring 64 first stage/channel alarm so unds which can be selected via an internal switch. The alarm tone frequencies for the first 2 stages are independently selectable. Each tone can be remotely triggered e.g. via an external relay, to change to a second, third or fourth stage/channel alarm sound.

Features:
  • Robust corrosion proof 316L stainless steel enclosure
  • High output, up to 115dB(A)
  • 4 remotely selectable alarm stages/channels
  • Positive or negative line stage/channel switching
  • Choice of 64 alarm tone frequencies
  • Automatic synchronisation on multi-sounder system
  • Continuously rated
  • Compact form factor
  • Stainless steel fixings
  • Ratchet adjustable 316 stainless steel bracket
  • 316 Stainless steel stopping plugs included
  • 3 x cable entries
  • Duplicate cable terminations (in & out for daisy-chain installations)
  • Available with custom tone configurations and frequencies
  • DNV type approved IEC 60945 & DNVGL-CG-0339
Approvals:
  • IECEx ULD 16.0017X
    IEC 60079-0 : 2011
    IEC 60079-1 : 2014
    IEC 60079-31 : 2013
  • ATEX DEMKO 16 ATEX 1466X
    EN 60079-0 : 2012 + A11 : 2013
    EN 60079-1 : 2014
    EN 60079-31 : 2014
  • TR-CU Ex EAC certificate: RU C-GB.AA71.B.00109
  • SIL1 compliant to IEC 61508 (2010)
Coding
  • Ex db IIC Gb T6 Ta -50°C to +65°C
  • Ex db IIC Gb T5 Ta -50°C to +70°C
  • Ex tb IIIC Db T85°C Ta -50°C to +70°C

Specification
Maximum output: 115dB(A) @ 1 metre [107dB(A) @ 10ft/3m]
Nominal output: 110dB(A) @ 1m +/- 3dB – Tone 2 [103dB(A) @ 10ft/3m]
No. of tones: 64 (UKOOA / PFEER compliant)
No. of stages: 4
Volume control: Adjustable -128 dB(A) [Tone 2 ]
Effective range: 125m/410ft @ 1KHz
Voltages DC: 24V dc (10-30V dc)
Voltages AC: 110-240V ac 50/60Hz
Stage switching: DC units: negative or positive
AC units: common supply line
Ingress protection: EN60529: IP66
Enclosure matl: 316L Stainless Steel
Enclosure finish: Chromated & powder coated
Colour: RAL3000 Red
Cable entries: 3 x M20 ISO (2 x stopping plugs included as standard)
Adaptors to M25, 1/2 " & 3/4" NPT can be specified
Terminals: 0.5 - 2.5mm2 (20-14 AWG)
Enclosure volume: <2 litres
Linemonitoring: Blocking diode included EOL Min. 500 O hm 2w, or 3k3 O hm 0.5w resistor or diode (DC versions) can be fitted
Grounding stud: M5
Temperature range: -50° to +70°C (-58°F to +158°F)
Relative humidity: 95% – Additional tropicalisation is recommended for applications where both high relative humidity and high ambient temperatures exist
Weight: 6.00kg/13.22lbs
Export Info
Made inUnited Kingdom
Harmonized Tariff Code (HTC)85318030

 Info/Quote Request
 Reseller & Volume Discounts
 Shipping & Handling

B2B Checkout Options: Designated Carrier and Tax-Exempt purchase
Payment Options: Credit Card, Credit Card Over the Phone, PAYPAL, Wire Transfer/Electronic Payment and Check

Checkout with Paypal Visa MasterCard Amex Checkout with Wire Transfer Electronic Payment
