Gas Leak and Flame Detectors, Analyzers, Alarm Devices and Calibration Gas
SKU# (6254)

BACHARACH  6302-4040

$740.70     Availability: 7 Days
 Info/Quote Request
 Shipping Rates
 Volume discount
BACHARACH 6302-4040 (1)
  • Overview
  • Features
  • Specs
  • CONSUMABLES
  • ACCESSORIES & RELATED
  • Literature

Bacharach MGS-460 Gas Detector Transmitter with remote (5m) electrochemical sensor for Carbon Monoxide (CO) 0-500ppm measurement in Refrigeration Applications. 3 x relays (low, high & fault), analog output (4 to 20 mA, 0 to 5 V, 0 to 10 V, 1 to 5 V, 2 to 10 V), RS485 MODBUS RTU output, included audible & visual alarms: 72dB @10cm buzzer and single tri-color LED (green, red, orange). IP66 Housing. CE, UL and CSA Approvals. Mobile App Bluetooth Interface.

$740.70

  Availability 7 Days  ]

FEATURES
  • Mobile App Interface
  • Simple Configuration via App
  • Remote Sensor (5 m cable)
  • Pre-calibrated Sensors
  • Semi-automated Calibration
  • Temperature-compensated Measurement
  • Analog and Digital Communications
  • On-board Relays
  • Audible and Visual Alarms
  • Multiple Cable Entries and Terminals
  • Low-temperature Performance
BENEFITS
  • Quick, easy and intuitive commissioning, configuration and maintenance requires no special training
  • No tools required to set alarm behavior and alarm levels
  • Install gas detection in hard-to-reach areas
  • Save time and money on maintenance procedures
  • Easy process with no potentiometers or volt meters
  • Mitigates false alarms and optimizes accuracy in refrigeration applications
  • Integrates with BMS / BAS control systems via Modbus and / or analog outputs
  • Trigger additional alarm beacons and mechanical ventilation in the event of a refrigerant leak
  • Comply with ASHRAE 15 / EN 378 - no additional hardware
  • Quick and easy installation of all wiring; daisy-chain power and digital communications
  • Suitable for use in all refrigeration applications from machinery rooms to freezers
DESCRIPTION

Bacharach’s MGS-460 Gas Detector makes compliance with refrigeration safety codes simple and easy, saving time and money on equipment and installation. The remote sensor allows for gas detection to be installed in hard-to-reach areas with a conveniently located electrical and communication interface. Using the MGS-400 App, users can intuitively use, commission and maintain their gas detection system without the need for specialty training or tools. Pre-calibrated sensor modules simplify maintenance, take minutes to exchange and do not require the use of calibration gas.

The MGS-460 can trigger additional audio-visual alarms and act as a standalone gas detection system, or integrate easily into a BMS / BAS or with Bacharach’s optional MGS-408 Gas Detection Controller.

MGS-460 TECHNICAL DATA
Gases and Ranges Refrigerants: 1,000 ppm
CO2: 5,000 / 10,000 / 20,000 / 30,000 / 40,000 / 50,000 ppm
NH3: 100 / 1,000 / 5,000 / 100% LEL
O2: 30 Vol%
CO: 500
Combustible gases - Semiconductor (R-290, R-600, R-50, R-600a, HC-12a, R-717): 5,000 ppm
Combustible gases - NDIR (R-600, R-50, R-290): 100% LEL
Combustible gases - Catalytic (R-600, R-50, R-290, R-717): 100% LEL
NO2: 20 ppm
Status Indicator Single tri-color LED (green, red, orange)
Buzzer 72dB @ 10 cm
Output Single configurable analog output: 4 to 20 mA, 0 to 5 V, 0 to 10 V, 1 to 5 V, 2 to 10 V
Digital: Modbus RTU via RS 485
Power Supply 24V AC or DC (auto selecting), 4W (max)
Relay Three relays, SPDT, fixed low / high fault alarms
Rating 2 A @ 30 VDC
Enclosure IP66
Size (W×H×D) Approx. General purpose (base): 6.5” × 6.5” × 3.4” (165 × 165 × 87 mm)
Remote head: 4.5” × 5.4” × 2.7” (115 × 136 × 68 mm)
Weight Approx. 1lb, 11.7oz (758 g)
Approvals CE, UL / CSA / IEC EN 61010-1
Ambient Temperature Semiconductor: -40 to 122°F / -40 to +50°C
Electrochemical:
NH3: 100 / 1,000 ppm: -40 to 40°C
NH3: 5,000 ppm: -20 to 40°C
CO: 500 ppm: -40 to 50°C
NO2: 20 ppm: -20 to 40°C
O2: 30% Volume: -20 to 50°C
Infrared: -40 to 122°F / -40 to +50°C
Catalytic Bead: -40 to 122°F / -40 to +50°C
Ambient Humidity 5 to 90 % RH, non condensing
Ambient Pressure 23.6 to 32.5 inch Hg / 800 to 1,100 mbar
Free Mobile AppConfiguration, Maintenance, Calibration, User Interface via Bluetooth
Export Info
Made inUnited States
Harmonized Tariff Code (HTC)9027102000
