The APS2-6R is a state-of-the-art, 150 watt, switching auxiliary
power supply providing 24 VDC of filtered DC power. The APS2-
6R provides three 24 VDC output circuits, rated for 6.0 Amps in
alarm and 4.0 Amps continuous. It is used for the operation of
peripheral audible/visual devices (alarm signaling appliances) for
the Onyx Series control panels.
The APS2-6R can also be used with Legacy panels. Please refer
to the APS2-6R manual for more information.
Features
- UL 864 Ninth Edition compliant
- Lightweight, compact design
- 120 or 220/240 VAC (@ 50/60 Hz) versions
- Output circuits with overload protection
- Built-in “brown-out” circuitry
- Diagnostic trouble LED
- Plug-in connector for in-cabinet applications and screw terminals for remote device applications
- Trouble supervision bus
- Shares battery and charger circuit with control panel
- Power-limited design, per UL requirements
- AC Fail supervision and reporting with field-selectable delay per UL 864
- Heavy-duty clamp-type terminals accept up to 12 AWG (3.1 mm²) wire
- Battery voltage supervision
- Low battery disconnect
- Mounts in a standard CAB-3/XLS-ADT-CAB-4 Series cabinet.
Construction and Operation
When used with the CAB-3 or CAB-4 Series (CAB-A3/-A4, -B3/-
B4, -C3/-C4, or -D3/-D4 one to four tiers), the APS2-6R mounts to
a CHS-4 or CHS-4L mounting chassis. If more than one APS2-6R
is necessary to satisfy Audible/Visual (DC) power requirements,
connect additional APS2-6R power supplies together as described
in the Installation Instruction Manual #53232.
Underwriters Laboratories requires that all Signaling Appliances
be approved for use with the selected control system due to volt-
age operating range criteria. Use only those appliances listed for
use with the associated control system. Refer to Device Compati-
bility Document #15378.
Installation Standards and Codes
This power supply complies with the standards set forth by the fol-
lowing regulatory agencies:
NFPA Standards
- NFPA 72 National Fire Alarm Code
Underwriters Laboratories:
- UL 864 Standard for Control Units and Accessories for Fire Alarm Systems.
In addition, the installer should be familiar with the following standards:
- NEC Article 300 Wiring Methods
- Applicable Local and State Building Codes
- Requirements of the Local Authority Having Jurisdiction
- The Canadian Electrical Code, Part 1
Agency Listings and Approvals
The listings and approvals below apply to the basic APS2-6R. In
some cases, certain modules may not be listed by certain approval
agencies, or listing may be in process. Consult factory for latest
listing status.
- UL/ULC S635
- FM Approved
- CSFM: 7315-0028:248
- FDNY: COA #6028
